Instrument Transformers, Oil-Immersed Voltage Transforer

Instrument Transformers, Oil-Immersed Voltage Transforer

Instrument Transformers are specially designed heavy-duty transformers built to supply high-current, low-voltage power to electric arc furnaces (EAF), ladle furnaces (LRF), and submerged arc furnaces (SAF). These transformers endure extreme thermal and mechanical stresses due to frequent short circuits and fluctuating loads inherent in furnace operations. Equipped with On-Load Tap Changers (OLTC) for precise voltage regulation, robust tank construction, and advanced cooling systems. Available from 1MVA to 100MVA, fully compliant with IS 2026, IEC 60076, and relevant industrial standards

0.00 AED 0.00 AED
  • Brand
  • Model
  • Type
  • Capacity Range
  • Voltage Classes
  • Rating
  • Frequency
  • Core Material
  • Winding Material
  • Cooling Type
  • Duty Cycle
  • Regulation
  • Current Rating (LV)
  • Vector Group
  • Brand Options
  • Installation

Sku: STE-T-IT-005
Brand: SPRINT ELECTRIC

Specification

Brand Sprint Electric
Model Instrument Transformers
Type Oil-Immersed / Special Duty
Capacity Range 1MVA to 100MVA
Voltage Classes 11 kV/110 V, 33 kV/110 V etc..class 0.2/ 0.5/3P
Rating 100 kVA to ~5 MVA
Frequency 50Hz / 60Hz
Core Material CRGO Silicon Steel (Step-Lap)
Winding Material Electrolytic Copper (High Current)
Cooling Type ONAN / ONAF / OFAF / OFWF
Duty Cycle Continuous / Intermittent
Regulation On-Load Tap Changer (OLTC)
Current Rating (LV) Up to 100kA (depending on MVA)
Vector Group Dyn11 / Dd0 / Special
Brand Options Siemens, Schneider, ABB, L&T, Legrand
Installation Indoor / Outdoor
